Description
T409HS.W.UK Specification Sheet
Construction and performance
- Inner drum: Stainless Steel
- Motor: Long life and quiet brushless motor
- Heating system: Heat pump
- Drying types: Sensor or time controlled
- Drum size: 117 L
- Easy to use lint filter: Yes
Use and flexibility
- Water tank volume: 6 L
- Door opening diameter: 340 mm
- Door maximum opening angle: 180 °
- Sensors: Moisture sensor
- Auto condenser filter cleaning: Yes
- Load Light™ – Illumination of the drum: Yes
Interaction and control
- Remaining time indication: Yes
- Type of display: LCD display
- Indication when program is ready: Yes
Programs and options
- Number of programmes: 16
- Drying programs: Auto terry / Auto jeans / Auto normal dry / Auto down / Auto synthetics / Auto dry / Auto iron dry / Auto extra dry / Bedding / Silk and wool / Shirts / Steam wrinkle care / Steam refresh / Quick Pro / Time program / Airing
- Settings: Load level setting / Steam programmes (Steam wrinkle care and Steam refresh) / Delayed start / Setting of dryness level / Timed drying / Anti-crease function
Design and integration
- Door hinge placement: Right/Left
- Adjustable feet: 15 mm
- Easy mounting of ASKO dryer on top of the washers: Yes
- Loading type: Front load
Safety and maintenance
- Lockable control panel: Yes
- Overheat protection: For motor and electronics
Technical data
- Noise level drying dB(A): 64
- Power consumption in standby mode: 0.8 W
- Estimated yearly energy consumption: 217 kWh
- Energy efficiency class: A++
- Plug type: GB
- Connected load: 2000 W
- Voltage (V): 220-240 V
- Number of phases: 1
- Fuse: 13 A
- Frequency: 50 Hz
- Net weight: 56.8 kg
- ISO 14001 certified manufacturing: Yes
Dimensions
- Width: 595 mm
- Height: 850 mm
- Depth: 654 mm
- Depth with door open: 1165 mm
- Length of electrical cord: 2100 mm
Logistic information
- Packaging width: 640 mm
- Packaging height: 920 mm
- Packaging depth: 723 mm
- Gross weight: 61.2 kg
- Product code: 738517
.
.
Soft Drum™ is a solution developed to enhance air flow around the load, thereby increasing the drying effect. The circular indentations with bevelled edges also have a cushioning effect that reduces wear and tear on fabrics. The new drum design allows for even and gentle drying with both small and large loads.
This smart feature is our own invention. It saves both the motor and your ironing board. The unique paddles inside the drum tumble the clothes in a figure eight to prevent the clothes from bundling. This leads to a reduced need to reverse the drum rotation. This is an intelligent function which saves the motor and the belt from any unnecessary strain and your clothes from creasing.
At ASKO, we believe not only that stainless steel will outlast for example, plastic, but also that quality materials will always look better in years to come. Eventually, galvanised steel rusts, so we decided to make our drums out of stainless steel. That’s why our tumble dryers really do last longer.
Regardless model you will have high definition displays with precise contrast, no flickering, low power consumption and visibility at an angle of 180°. Key words are easy-to-use, clarity and feedback – all important ingredients to make the full functionality accessible to you. The interfaces are carefully designed to encourage you to explore all functions and find the best programs, options and settings for your varying fabrics, dirtiness levels and soiling types. You can create your own personal programs using the different modes and options and then save them as favourites to be able to find them quickly the next time you wash or dry.
You have the possibility of selecting 3 load levels: small, medium and heavy. This function is practical for optimising drying time depending on the amount of clothing.
The heat pump dryer consumes only 0.24 kWh/kilo laundry. This combined with the Sensi Dry™ system and the Auto programs makes ASKO a good option for the environmental conscience customer.
ASKO tumble dryers have brushless motors to keep noise as low as possible and service life as long as possible.
Selected ASKO heat pump dryers have a self-cleaning condenser filter that automatically flushes water through the filter. No need to worry about clogged filters anymore.
The Steam refresh program effectively remove odours from delicate items. Instead of going to the dry cleaner’s, just put the item in the dryer and save both time and Money.
By using the Auto Synthetic program with its lower temperature and shorter tumbling time, you will automatically take care of your blouses and shirts the right way.
The Silk & Wool program loosens up and refreshes wool and silk garments that have lost their original features. The gentle program makes your garments last longer.
The Multi Filter System effectively traps all lint before reaching more sensitive parts of the tumble dryer. This keeps the drying times shorter and the machine up and running.
The ASKO Sensi Dry™ system measures moisture in and around the machine, which prevents unnecessary over-drying as well as wear and tear on your clothes.
Use the Airing option to freshen up your clothes or get rid of hair from your pets. Cool tumbling for any length of time can be used also for delicate garments.
The Anti-crease automatically rotates the drum for three seconds every minute to prevent your clothes to wrinkle. The program runs for two hours after the program is finished.
All our tumble dryers are designed according to the Line Concept™, which offers a logic way of using the machines, from left to right.
.
.
.
